Block frame MB Barbell

1. Torso muscles (abs).

2. Arm muscles (biceps, triceps, delta).

3. Leg muscles (muscles of the back, inner, outer thighs, gluteal muscles).

• The supporting structure is made of a 60x60 mm profile with a wall thickness of 2 mm.
• The design has radial bends, which significantly increases its strength.
• The frame is painted using powder coating.
• A weight block consisting of steel plates coated with PVC is used as a weighting material, which makes the work on the simulator silent.
• • The load block is driven by a polyamide belt 20 mm wide, 2.6 mm thick, with a tensile strength of 390 N/mm2, with a maximum load of 1500 kg.
• • Power transmission is carried out through only 2 roller blocks, which simplifies the design and increases the reliability of the mechanism.
• The exercise machine is equipped with a handle for traction.
• The load is adjusted by rearranging the adjusting pin (clamp) attached to the elastic cord.
• The flute and guides are fully plated with nickel and chrome.
• The load block protection is made of impact-resistant polystyrene.
• Ball bearings installed on all rotation units ensure reliable and comfortable use of the simulator.
• To prevent slipping, the product is equipped with PVC bearings.

Exercises:

1) Biceps curl.

2) Triceps extension.

3) Taking the leg to the side/back.
